Mono-Lock Structural Rivet(Stainless steel)

SIZE : DIA 4.8MM TO 9.8MM LENGTH 10MM TO 21MM

MATERIAL : BODY:304&316 STAINLESS STEEL;MANDREL:304&316 STAINLESS STEEL

FINISH : NATURAL POLISH

PACKAGING : BULK PACK | SMALL BOXED

Description Specification Related Products Form

Description

  • Excelleirs hole filling property and vibration resistant effect are realized by rapidly expanded rivet body, which can provide sup- plementary riveting for the irregular and over tolerance holes, oval or malposition holes.



  • Good large-gap closing ability and strong clamp force of sheets.



  • Mechanical mandrel locking mechanism which avoids damage, electric leakage or marowak sound caused by the loosening of mandrel.



  • Large riveting grip range.



  • High shear and tensile strength.



  • Visual external locking system which is convenient for rapidly and simply checking whether the installation is in place.

Specification

Size

D

E(Max)

F(Max)

H(Max)

P(Min)

W(Max)

Hole Dia

Grip Range

Tensile ref.

Shear ref.

Breaking Load(Max)

Retention Load(Min)

4.8 x 10

4.8

2.2

18.2

10.1

27

3.1

4.9-5.1

1.6-6.5

5100N

6400N

7000N

445N

4.8 x 14

24.4

1.6-11

6.4 x 14

6.4

3

26.7

13.4

27

4.1

6.7-7

2.1-9.5

9000N

11000N

12000N

1112N

6.4 x 19

36.5

2.1-16

9.8 x 21

9.8

4

36.2

20

27

6.15

10-10.4

3-16

19400N

26080N

20000N

2400N
