STANDARD : DIN 933,ISO 4017, DIN 961, ISO 8676, DIN558SIZE : M3 - M52 LENGTH 6 - 200MMMATERIAL : CARBON STEEL, STAINLESS STEEL, BRASSGRADE : 4.8 5.8 6.8 8 10.9 12.9 A2-50 A2-70 A4-70 A4-80FINISH : SELF COLOUR ,ZINC PLATED, HDG,ZINC FLAKEPACKAGING : BULK PACK | SMALL BOXED
STANDARD : DIN985SIZE : M3 - M48MATERIAL : Carbon Steel,Stainless SteelGRADE : 6, 8, 10, A2, A4FINISH : PLAIN | BZP | Mechanical Galv | GEOMET ...PACKAGING : BULK PACK | SMALL BOXED
STANDARD : DIN 934SIZE : M2.5 - M100MATERIAL : STEEL GRADE 8, 10, 12GRADE : 6, 8, 10, 12, A2, A4, BRASSFINISH : PLAIN | BZP | HDG | GEOMET ...PACKAGING : BULK PACK | SMALL BOXED
STANDARD : N/A
SIZE : M3.5-M4.8
MATERIAL : CARBON STEEL, STAINLESS STEEL
FINISH : ZINC PLATED, PHOSPHATE, ZINC FLAKE; SELF COLOUR
PACKAGING : BULK PACK | SMALL BOXED
• Phillips Drive Recess.
•Screws are made from hardened C1022 steel.
•Extra deep insert bit recess offering a firmer positive drive.
•Extremely sharp piercing point.
• Thread gives speedy insertion and improved holding power.
• Bugle head allows the screw to sink effortlessly into the dry lining without the need for countersinking.
• Bugle head minimises damage to the surface enabling a smoother surface finish.
| Gauge | Coarse P | d2 | d1Max | d1Min | Recess No |
| 3.5 | 2.82 | 8.5 | 2.35 | 2.05 | 2 |
| 3.9 | 2.82 | 8.5 | 2.5 | 2.2 | 2 |
| 4.2 | 3.18 | 8.5 | 2.85 | 2.55 | 2 |
| 4.8 | 3.18 | 9.4 | 3.35 | 3.05 | 2 |
| Gauge | Fine P | d2 | d1Max | d1Min | Recess No |
| 3.5 | 1.5 | 8.5 | 2.3 | 2 | 2 |
| 3.9 | 1.5 | 8.5 | 2.55 | 2.25 | 2 |
| 4.2 | 1.7 | 8.5 | 2.8 | 2.5 | 2 |
| 4.8 | 2.1 | 9.4 | 3.35 | 3.25 | 2 |
